СТАНДАРТНЫЕ И МОДИФИЦИРОВАННЫЕ контактные кольца

LPC-1C3002 integrated slip ring

LPC-1C3002 integrated slip ring

  • Working Speed:0~300rpm
  • Contact Material:Gold to Gold
  • Housing Material:Aluminum Alloy
  • Frequency range:0~3GHz
  • Contact Material:Precious Metal
ДОКУМЕНТАЦИЯ СВЯЗАТЬСЯ С НАМИ
Характеристики модели

LPC-1C3002 is a hybrid high frequency and electrical slip ring with an outer diameter of 24.8mm and a length of 62.3mm. This high frequency coaxial rotary joint is optional with and without an elbow design which offers more flexibility to fit in different platform. The slip ring features high design precision, low contact resistance, low torque, long service life and reliable operation. This slip ring   is especially fit for small rotary systems that transmit weak control signals. It is compatible with data bus protocal and SDI signals.
