JINPAT High Frequency Rotary Joints for Military Radar System
Rotary joints, also called slip rings, are important electrical components that facilitate the transmission of energy and signals between a rotating part and a stationary part. There are different types of slip rings that are suitable for specific purposes. In the case of military radars, which are widely used to determine the orientation of an […]
Information
Rotary joints, also called slip rings, are important electrical components that facilitate the transmission of energy and signals between a rotating part and a stationary part. There are different types of slip rings that are suitable for specific purposes. In the case of military radars, which are widely used to determine the orientation of an object in a military defense system, in addition to being able to rotate the radar antenna 360 degrees, the rotary joint or slip ring must ensure reliable data transmission. JINPAT high-frequency rotary joint or RF slip ring is an ideal slip ring solution for military radar systems.
JINPAT RF Slip Ring, transmits analog signals from 500MHz to 50GHz. RF slip rings can be divided into single-channel RF rotary joints and multi-channel rotary joints.
RF slip rings developed by JINPAT help simplify the design of military radar system, eliminate the twinning of terminals, and thus ensure smooth 360-degree rotation of the antenna while maintaining excellent data transmission performance.
Features and Benefits
◆ High frequency transmission
◆ Anti-electromagnetic interference
◆ Hybrid precision swivel joints
◆ Reliable performance, no p data
◆ Ultra-low attenuation loss, low electrical noise
◆ Small and lightweight, with compact design
◆ Waterproof, pressure and vibration resistance
◆ Work in a wide temperature range
◆ Long service life
◆ Free support
◆ Cost-effective
◆ Fast delivery Keywords RF swivel joints RF swivel joints
