Customized Rotary Transmission for Demanding Applications

Rotating equipment used in industrial and specialized environments can face vibration, dust, moisture, temperature variations, and limited installation space.

A conventional slip ring may not provide enough flexibility for these requirements.

The LPC-D37-45S-03SD2-01E3-IP54 is a fully customized rotary transmission solution designed for applications requiring multiple signal types and application-specific mechanical construction.

13 Signal Groups in One Rotary Interface

The product integrates 13 signal groups, including:

• Gigabit Ethernet
• 3G-SDI
• Other customized signal channels

Depending on the system, the rotary interface can also be configured for USB 3.0, fiber optic, RF coaxial, power, and control signals.

This integrated approach can reduce the need for multiple independent rotary connections.

High-Speed Signal Protection

High-speed communication and video signals require careful electrical design.

JINPAT can optimize the signal transmission path through:

• Impedance matching
• Crosstalk shielding
• Signal isolation
• Customized connectors
• Specialized internal wiring

This is particularly important for systems combining Ethernet and video transmission.

Specialized Materials and Components

The product uses a fully non-standard construction.

Depending on the application, specialized materials and components can be incorporated, such as:

• Heat-shrink tubing
• Braided shielding
• Special connectors
• Terminals
• Customized internal materials

This allows the slip ring to be adapted to different equipment structures.

Protection and Environmental Adaptation

The product features IP54 protection.

For specialized applications, the mechanical design can also be developed according to environmental requirements such as:

• High vibration
• High vacuum
• Moisture
• Dust
• Other demanding operating conditions

Applications

The LPC-D37-45S-03SD2-01E3-IP54 is suitable for:

• Pan-tilt platforms
• Optical equipment
• Industrial monitoring systems
• Rotating machinery
• Robotics
• Specialized automation equipment

Key Features

✔ Fully customized design
✔ 13 signal groups
✔ Gigabit Ethernet + 3G-SDI
✔ High-speed signal optimization
✔ Customized shielding
✔ Specialized materials
✔ IP54 protection

Conclusion

The LPC-D37-45S-03SD2-01E3-IP54 is designed for rotating equipment that requires more flexibility than a standard slip ring can provide.

Its combination of multi-signal transmission, customized materials, signal optimization, and IP54 protection makes it suitable for demanding industrial and rotating applications.
