The JINPAT heavy current integrated slip ring is a high-performance rotary transmission system designed for demanding marine and industrial environments. It integrates power, signal, fluid, gas, and fiber optic transmission into a single compact structure.

This solution ensures stable operation under high voltage, heavy current, and complex working conditions.

Key Features

High Voltage & Heavy Current Transmission

• 6 circuits supporting up to 3300V
• Current capacity up to 720A per channel
• Stable continuous power transmission under heavy load

Fluid and Gas Integration

• 8-channel fluid transmission (up to 5MPa)
• 2-channel gas transmission

Suitable for hydraulic and pneumatic systems in marine equipment.

Signal & Fiber Optic Transmission

• Ethernet signal transmission support
• 6-channel multi-mode fiber optic rotary joint

Ensures high-speed and stable data communication.

Built-in Environmental Control

• Heating system for low-temperature environments
• Cooling and dehumidification system
• Temperature monitoring sensors
• 180° angle indication system

Modular Structure

• Quick-connect design
• Copper busbar connection
• Stackable modular structure

Easy installation and maintenance.

Applications

• Marine engineering systems
• Offshore platforms
• Heavy-duty cranes
• Port machinery
• Industrial automation equipment

Conclusion

The JINPAT heavy current integrated slip ring provides a reliable and fully integrated solution for power, signal, and fluid transmission in rotating systems, ensuring long-term stable performance in harsh environments.
