Q: What environment is the LPPL050-0530-01E3-02A rated for?
A: It’s rated for vacuum/pneumatic conditions down to -30kPa, which suits the clean, controlled environments used in lithium battery and new energy battery manufacturing.
Q: Can a single slip ring carry both power and data?
A: Yes — the LPPL050-0530-01E3-02A combines 5 power circuits at 30A each with one Gigabit Ethernet channel and two integrated pneumatic passages in one compact housing.
Q: What is the LPA000-02200-01PE-0610 (JP13-345-09) used for?
A: It’s a high-current waterproof connector designed for the new energy sector, with EV charging stations/piles as its primary application, alongside broader new energy equipment where high current and outdoor exposure both apply.
Q: What does its IP65 spray test actually involve?
A: Water is sprayed through a 6.3mm nozzle at a flow rate of (12.5±0.625) L/min, from a distance of 2.5m–3m, for 5–10 minutes, with at least 1 minute of spray coverage per square meter of housing surface — a standard designed to simulate sustained outdoor rain/washdown exposure.
Q: Does the high-current rating require a larger housing?
A: No. The connector’s compact structural design supports high-current transmission without increasing the installation footprint, which matters for space-constrained charging pile enclosures.
Q: How is heat managed during high-current operation?
A: A built-in temperature control system monitors and manages heat buildup during operation, supporting stable performance across repeated charging or load cycles.
Q: What industries use these products?
A: The compact slip ring is used mainly in lithium battery and new energy battery production. The high-current waterproof connector is used in new energy equipment and EV charging infrastructure.
Q: Which model is right for my application?
A: If you need a compact footprint with combined power and data transmission, the LPPL050-0530-01E3-02A is the better fit. If you need a high-current connector with outdoor-grade waterproof protection and thermal management, the LPA000-02200-01PE-0610 is designed for that. Send us your operating conditions and we’ll help confirm the right spec.
