LPC-1C2402 integrated slip ring

LPC-1C2402 integrated slip ring

  • Working Speed:0~300rpm
  • Contact Material:Gold to Gold
  • Housing Material:Aluminum Alloy
  • Frequency range:0~3GHz
  • Housing Material:Brass
Downloads CONTACT US
Model List

LPC-1C2402 is a hybrid high frequency and electrical slip ring with an outer diameter of 22mm and a length of 54.8mm. This high frequency coaxial rotary joint is optional with and without an elbow design which offer more flexibility to fit in different platform. The slip ring features high design precision, low contact resistance, low torque, long service life and reliable operation. This slip ring   is especially fit for small rotary systems that transmit weak control signals. It is compatible with data bus protocal and SDI signals.

LPC-1C2402integrated slip ring.jpg
